RESILIENT SOUNDS PLATINUM V2 18" DUAL 1 OHM (D1) SUBWOOFER

The Pinnacle of Competition-Grade Low-Frequency Output

The Resilient Sounds PLATINUM V2 18" D1 is purpose-built for the most extreme and competitive audio systems, delivering maximum output at ultra-low impedance. This flagship 18-inch subwoofer maintains a conservative 2,500W RMS rating, utilizing a 13% larger motor and a 20% longer 3-inch 8-layer voice coil to provide unmatched force and thermal stability. The Dual 1 Ohm impedance is the definitive configuration for maximizing amplifier power, allowing for an incredibly low 0.5 Ohm final load when wired in parallel. With a colossal 35mm XMAX, the Platinum V2 18" pushes the boundaries of low-frequency reproduction with authority, speed, and precision.



TECHNICAL SPECIFICATIONS

Specification	Detail
Model	Platinum 18 V2
Nominal Impedance	Dual 1 Ohm (D1)
RMS Power Handling (Conservative)	2,500 Watts
Peak Power Handling	5,000 Watts
Maximum Excursion (XMAX)	35MM
Voice Coil	3-inch 8 Layer (20% Longer than V1)
Motor Structure	13% Larger Motor, XL Triple Stacked
Cone / Dust Cap	Carbon Fiber
Surround	New High Roll Tooled Surround
Spider / Leads	10" Spider Pack with Insulated Dual Leads
Frame/Basket	Cast Aluminum Frame



RECOMMENDED ENCLOSURE SPECIFICATIONS

Internal Volume (Cubic Ft)	4 - 6 CU FT
Tuning Frequency	28 - 33 HERTZ
Port Area	12 - 16 SQ INCHES OF PORT AREA PER CUBIC FT
Mounting Depth	12.5 INCHES
Cutout Diameter	16.93 INCHES
Displacement	0.33 CUBIC FT
