RESILIENT SOUNDS GOLD V2 15" DUAL 2 OHM (D2) SUBWOOFER

Unleash Deep Bass Power with the Resilient Sounds

The Resilient Sounds GOLD V2 15" D2 is designed to maximize output from amplifiers rated for 1 Ohm stability. Sharing the robust foundation of the GOLD V2 line, it handles a conservative 1500W RMS and features an advanced motor assembly, including a 3-inch 4-layer voice coil and 31mm of linear excursion (XMAX). This subwoofer is engineered for those who prioritize massive bass output and require a low-impedance setup. The Dual 2 Ohm voice coil configuration makes it perfectly suited for wiring two woofers to a 1 Ohm final load or a single woofer to a 4 Ohm load, offering unparalleled flexibility in high-power car audio systems.



TECHNICAL SPECIFICATIONS

Specification	Detail
Model	Gold V2 15"
Nominal Impedance	Dual 2 Ohm (D2)
RMS Power Handling (Conservative)	1500 Watts
Maximum Excursion (XMAX)	31MM
Voice Coil	3-inch 4 Layer (25% Longer than V1)
Motor Structure	Triple Stack 220mm Motor with Venting (15% Larger than V1), Engraved Bottom Plate, Molded Motor Boot
Surround / Spider	NEW High Roll Tooled Surround, 10" Spider Pack with Dual Sewn Leads
Frame/Basket	Cast Aluminum Frame
Terminals	4 Ga Push Terminals
Gasket	Aluminum Gasket
Shorting Ring	Aluminum
Available Sizes	10", 12", 15", and 18"



RECOMMENDED ENCLOSURE SPECIFICATIONS

Internal Volume (Cubic Ft)	2.25 - 3.25 CU FT
Tuning Frequency	28 - 32 HERTZ
Port Area	12 - 16 SQ INCHES OF PORT AREA PER CUBIC FT
Mounting Depth	10.375 INCHES
Cutout Diameter	14.2363 INCHES
Displacement	0.24 CU FT
Outside Diameter	15 7/32 INCHES
